Process and equipment

High-speed precision cutting production line

• 1. Manufacturing class one and manufacturing class two



  Make a lesson



  Manufacturing Lesson Two



  DMG MORI horizontal center processing machine



  Six-axis robotic arm

• 2. Tool Management Room





• 3. Production equipment details

  Item	name	Type	Mechanical specifications	Quantity
  1	DMG MORI horizontal center processing machine	6300	X:1050 Y:900Z:1030	2
  2	YOU JI horizontal center processing machine	HMC-630BP	X:1050 Y:750 Z:1000	1
  3	MAZAK horizontal center processing machine			1
  4	MAZAK Center Processing Machine			1
  5	FANUC six-axis robotic arm	M20iA	Up to a radius of 1813mm	2
  6	Center cutting machine	1500 (fourth axis)	X:1500 Y:700	2
  7	Center cutting machine	1500(Plane machine)	X:1400 Y:700	1
  8	Center cutting machine	1400 (fourth axis)	X:1400 Y:700	2
  9	Center cutting machine	1100(Plane machine)	X:1100 Y:600 Z:600	1
  10	Center cutting machine	1100 (fourth axis)	X:1100 Y:600 Z:600	30
  11	Center cutting machine	1000(Plane machine)	X:1020 Y:610 Z:610	6
  12	Center cutting machine	1000 (fourth axis)	X:1020 Y:610 Z:610	7
  13	CNC Turning and Milling Machine	FNL-250Y	X:260 Y:600	1
  13	CNC lathe	FS-300	X:290 Z:640	2
  14	CNC lathe	FBL-200	X:175 Z:650	1
  15	CNC lathe	UL-15	X:300 Z:455	2
